Power Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial Steelwork

  • Power Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial Steelwork
  • Power Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial Steelwork
Place of Origin China
Brand Name Shandong Xinghua Steel Structure
Certification EN1090 CE, ISO3834, ISO15614, AWS D1.1, ISO 9001/14001/45001
Minimum Order Quantity 10 tons
Price USD/tonne (FOB Qingdao or any Chinese port of loading); final price subject to project drawings.
Packaging Details Bundled, crated, rack-packed or nude (per member type); shipped by container load or breakbulk vessel.
Delivery Time 20–25 days after drawing confirmation & deposit; subject to project scope and quantity.
Payment Terms T/T;30% or 50% deposit, balance before shipment to designated port.
Supply Ability min. 5,000 tons/month (80,000 tons/year)
Product Details
Business Type Manufacturer (Original Factory) Customization OEM/ODM; Drawings By Client Or Our In-house Team
Inspection SGS/BV/TÜV/Intertek, Third-party Accepted. Warranty 12 Months From B/L Date; Covering Fabrication And Material Defects.
After-sales Service On-site Erection Guidance & Technical Support. Steel Grade Q235B/Q355B (GB/T 1591); S355JR (EN 10025); ASTM A36 / A572 Gr50
Workshop Crane Capacity Up To 100 Tons Max. Single-piece Fabrication Weight Up To 100 Tons
Max. Single-piece Fabrication Height Up To 6 Meters （Assembly Height Per Client's Requirement & Design Drawings) Max. Truss Segment Length Up To 40 Meters （Assembly Length Per Client's Requirement & Design Drawings)
Highlight

Quick Construct metal workshop building

,

metal workshop building Anti fatigue

,

prefab workshop garage for Light
Leave a Message
Product Description

Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial Steelwork



Main Features

A Q355B structural steel support system for power plant boilers, turbines and auxiliary equipment, designed for high-temperature, fatigue-loaded and heavy-duty service.

  • Q355B structural steel main frame, designed for high-temperature service zones

  • Heavy load capacity for boiler, turbine, HRSG and auxiliary equipment

  • Thermal expansion compensation to prevent stress concentration

  • Fatigue-resistant design for cyclic temperature and pressure loading

  • Full platforms, walkways, stair towers and pipe supports

  • High-rate welding with UT/MT/RT NDT inspection

  • Modular prefabrication to shorten on-site construction cycle

  • Designed to GB 50017 / GB 50229, EN 1993 and ASME/IEC requirements

  • Corrosion protection: Sa2.5 + epoxy coating for plant environments

  • Designed and detailed for client's process loads and equipment layout



Techinical Specifications

Parameter

Value

Design Loads

Dead/live per process loads; seismic GB 50011 / EN 1998; wind up to 35 m/s

High-Temperature Design

Thermal expansion compensation ±150 mm; heat-resistant steel / fireproofing at hot zones

Fatigue Design

Cyclic temperature & pressure loading

Welding & NDT

GB 50661 / AWS D1.1 / EN 1090-2; UT/MT/RT

Design Standards

GB 50017 / GB 50229, EN 1993, ASME/IEC

Corrosion & Fire Protection

Sa2.5 + epoxy ≥125 μm; HDG optional; fireproof coating





Advantages

  • Heavy-duty structural support ensures stable boiler and turbine operation.
  • Fatigue-resistant design and thermal expansion compensation for long service life.
  • High-temperature service design adapted to extreme power plant conditions.
  • High welding quality with UT/MT/RT NDT and full material traceability.
  • Compliant with GB 50017 / GB 50229, EN 1993 and ASME/IEC requirements.
  • Modular prefabrication cuts construction cycle by 6+ months vs site-built methods.
  • Certified to EN 1090-2 + ISO 9001; proven in coal-fired, gas and HRSG projects.



Applications

  • Coal-fired and gas-fired power plants

  • Combined-cycle and HRSG power stations

  • Boiler support structures and boiler islands •

  • Turbine and generator support frames

  • Biomass and waste-to-energy plants

  • Cogeneration and district heating facilities

  • Industrial boiler and kiln support structures

  • Cement plant and metallurgy process structures

  • Petrochemical and refinery equipment structures

  • Desalination and energy plant steel structures

Power Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial SteelworkPower Plant Boiler Support Steel Structure, Q355B High-Temperature Heavy-Duty Industrial Steelwork
